What Is the Nexakey NX-NC510 Parking Guidance Node Controller?
The Nexakey NX-NC510 is a node controller for the NEXA PARK guidance system. It connects up to 25 zone controllers and communicates over CAN at distances up to 1000 m. It has a galvanised steel housing and operates from −30 °C to +75 °C.
- Up to 25 zone controllers
- CAN communication up to 1000 m
- Galvanised steel housing
- Operates from −30 °C to +75 °C
How Does the NX-NC510 Node Controller Work?
Ultrasonic sensors above each bay light their own indicator green or red. Up to 25 sensors daisy-chain to a zone controller, which takes up to 50. Up to 25 zone controllers then report to the node controller over CAN. Node controllers report to the central controller, which updates the aisle displays and entrance board in real time.
Where Does the Node Controller Sit in the Guidance System?
It sits between the zone controllers and the central controller. Zone controllers report to it, and it reports upward. The same architecture scales from one floor to 31,250 bays.
How Far Can the NX-NC510 Communicate?
The NX-NC510 communicates with zone controllers over CAN at distances up to 1000 m. This lets you cover large floor plates and multi-level car parks without adding extra infrastructure.
Why Choose Ultrasonic Guidance Instead of Cameras?
Camera-based guidance depends on reading number plates, and these systems do not reliably read Bangla-script plates. Ultrasonic detection does not read plates at all. Occupancy and guidance therefore work correctly on Bangladeshi plates, whatever their script or condition.
Why Plan the Cable Layout Before Choosing Controllers?
The controller count follows the cable layout. A zone controller takes up to 50 sensors, and a node controller takes up to 25 zones. We need your floor plan before any quotation is meaningful.
Does the NX-NC510 Work in Bangladeshi Basements?
Yes. It operates from −30 °C to +75 °C, comfortably inside a Bangladeshi basement. In a full basement, drivers circling for a space are the real congestion. A free-space count at the entrance and arrows at each junction remove most of that circulation.
Where Can You Use the NX-NC510 Node Controller?
Use it wherever a car park needs guidance across many zones:
- Shopping mall basements: removes the circling that causes congestion
- Hospital car parks: helps stressed visitors find a space quickly
- Airport and transport car parks: guides drivers across large floor plates
- Commercial office towers: manages tenant and visitor floors with different occupancy
- Mixed-use developments: serves several levels with different user groups and peak times
What Is the NX-NC510 Price in Bangladesh?
DigiMark Solution quotes the NX-NC510 as a Project Solution item. We design the system around your floor plan, because the component count follows your layout. Send your floor plan and we will prepare a quotation.
Why Buy the NX-NC510 From DigiMark Solution?
DigiMark Solution has supplied security and automation hardware in Bangladesh since 2006 and is a member of BCS and DCCI.
- Authorized supply: you get genuine firmware, correct accessories, and a locally honoured warranty
- Local service: our Dhaka and Chattogram branches provide spares, support, and on-site commissioning
- Survey before quote: we survey your site free of charge and confirm the design before quoting
- One accountable supplier: we integrate barriers, terminals, guidance, and software as one system
