| System |
| Main Processor |
Embedded Processor |
| Operating System |
Embedded LINUX |
| Video and Audio |
| Analog Camera Input |
4/8 Channel, BNC |
| HDCVI Camera |
1080P@25/30fps, 720P@25/30fps |
| AHD Camera |
1080P@25/30, 720P@25/30fps |
| TVI Camera |
1080P@25/30, 720P@25/30fps |
| CVBS Camera |
PAL/NTSC |
| IP Camera Input |
4CH: 4+1, each channel up to 2MP, 8CH: 8+2, each channel up to 5MP |
| Audio In/Out |
1/1, RCA |
| Two-way Talk |
Reuse audio in/out, RCA |
| Recording |
| Video Compression |
H.264 |
| Resolution |
1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
| Record Rate |
Main Stream:
4CH: All channel 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF(1~25/30fps), 8CH: the 1st channel 1080N/720P(1~25/30fps), others 1080N(1~12fps)/720P(1~15fps); 960H/D1/HD1/BCIF/CIF/QCIF(1~25/30fps)
Sub steram:
4CH: CIF/QCIF (1~15fps), 8CH: CIF/QCIF (1~7fps)
|
| Video Bit Rate |
32Kbps ~ 4096Kbps Per Channel |
| Record Mode |
Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Record Interval |
1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Audio Compression |
AAC(only for the 1st channel), G.711A, G.711U, PCM |
| Audio Sample Rate |
8KHz, 16 bit Per Channel |
| Audio Bit Rate |
64Kbps Per Channel |
| Display |
| Interface |
1 HDMI ,1 VGA |
| Resolution |
1920×1080, 1280×1024, 1280×720, 1024×768 |
| Multi-screen Display |
When IP extension mode not enabled: 4CH: 1/4
When IP extension mode enabled: 4CH: 1/4/6
|
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
