PA & Conference System MP9312U 120W Ultra-thin Digital Mixer Amplifier
MP9312U 120W Ultra-thin Digital Mixer Amplifier
MP9312U 120W Ultra-thin Digital Mixer AmplifierMP9312U 120W Ultra-thin Digital Mixer Amplifier

MP9312U 120W Ultra-thin Digital Mixer Amplifier

not inserted
Price 0
Status Pre Order
Product Code PR00641
Brand DSPPA
Model MP9312U 120W Ultra-thin
Features

    • Rated power 120W, 100V speaker output
    • Digital amplifier module, high efficiency (85%)
    • Built-in USB & Bluetooth module
    • 2 AUX & 2 Mic inputs & 1 AUX output

Hotline: 01979234344 | Corporate: 01979234316
Download Brochure
Share On :
Last Modified On: 30-12-2021

The following is prescribed feature of MP9306U digital mixing amplifier. It's also called sound digital amplifier. Each AUX & Mic input with individual volume control,Mic 1 of 6.35mm in front panel, with priority & muting,With priority input and 100V input,1 U compact design, space and cost saving



Digi-Mark Solution authorized distributor of DSPPA in Bangladesh. You can buy the DSPPA MP9312U 120W Ultra-thin Digital Mixer Amplifier  at best and dealer price from Our Head Office (Dhaka, Motijheel), IDB branch, Multiplan branch, Uttara Branch, Chittagong (chattagram) showrooms. For Lowest, dealer and best price Contact Us at 01979-234344.

Model

MP9312U

Rated Output Power

120W (Note: Please use a constant-voltage speaker within the power range)

Rated Output Voltage

100V

MIC1 IN

0.005(±1mV)

MIC2 IN

0.006(±1mV)

LINE1 IN,LINE2 IN,

PRIORITY IN

0.3(±20mV)VRMS

PRIORITY IN-100V

100 VRMS

MIC1,MIC2,LINE1 IN

≥74db(MAX.)

LINE2 IN,INPUT PRIORITY

≥80dB(MAX.)

Frequency Range

80Hz-15kHz (±3dB)

THD

≤0.5%  (1K under normal working condition)

Working Voltage

AC220V/50Hz

Bass

±10dB(100Hz)

Treble

±10dB (10kHz)

Rated Power Consumption

150W

75W

Package Dimensions (L×W×H)

310×275×120mm

Machine Dimensions (L×W×H)

200×190×44mm

Net Weight

1.5kg

Gross Weight

2kg
