| Protocols/Standards |
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR-069, 802.1x, TLS, SRTP, IPV6 (pending), OpenVPN (pending) |
| Network Interface |
Auto-sensing Gigabit Ethernet port with integrated PoE+ (IEEE 802.3at Class4) |
| Graphic Display |
4.3” IPS LCD with 800x480 resolution |
| Mic |
3 cardioid microphones; 12 ft. pickup distance, 360° capture |
| Speakerphone |
Frequency: 220-18,000 Hz
Volume: Up to 86 dB at 0.5 meter
Audio full duplex |
| Bluetooth |
Yes, integrated. Bluetooth 4.0 |
| Wi-Fi |
Yes, integrated. 802.11 b/g/n |
| Auxiliary Ports |
3.5mm audio port, USB Micro-B, RJ48 daisy chain port |
| HD Audio |
Yes, speakerphone with support for wideband audio |
| QoS |
Layer 2 QoS (802.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS. |
| Security |
User and administrator level passwords, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1x media access control |
| Physical |
Unit dimension:280mm(W) x 285mm(L) x 60mm(H) Unit weight:1.34kg; Package weight: 2.35kg |
| Temperature and Humidity |
Operation: 0°C to 40°C Storage: -10°C to 60°C Humidity: 10% to 90% Non-condensing |
