Description:
1. Collinear Load Test 180kg,350pounds.
2. Dual Voltage 12 or 24 VDC(optional).
3. The Standad Voltage is 12VDC when Finished.
4. MOV Provides Reverse Current Protection.
5. Anti-Residual Magneism Designed.
6. High Strength Material,Anodized Aluminum Housing.
7. Design with no Mechanical Bolt.
8. Increase the holding Force,Dual Insulative Hosing.
9. CECertificate by European Union,MA Certificate by China Public Security Office.
Specifications:
| Product Parameter | Parameter Description |
| Size | 170L*42W*21H(mm) |
| Armature Plate Dimension | 130L*33W*9H(mm) |
| Holding Force | 180kg(350Lbs) |
| Input Voltage | 12 or 24VDC |
| Current | 12V/300mA or 24V/150mA |
| signal output | No |
| Operating Temp | -10~+55℃(14-131F) |
| Humidity | 0~90%(non-condensing) |
| Cover Finish | Anodized aluminum |
| Lock Finish | Zinc |
| Armature Plate Finish | Zinc |
| Weight | 1.2KG |
