| Camera |
| Image Sensor |
1/1.9" progressive scan CMOS |
| Min. Illumination |
Color: 0.005 Lux @(F1.5, AGC ON) B/W: 0.002 Lux @(F1.5, AGC ON) 0 Lux with IR |
| White Balance |
Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| Gain |
Auto/Manual |
| Shutter Time |
50Hz: 1 to 1/30,000 s 60Hz: 1 to 1/30,000 s |
| Digital Zoom |
16 × |
| Day &Night |
IR cut filter |
| Privacy Mask |
24 programmable privacy masks, mask color configurable |
| Digital WDR |
Yes |
| Lens |
| Focal Length |
5.9 to 177 mm, 30 × Optical Zoom |
| Zoom Speed |
Approx. 4.8 s (Optical Lens, Wide-Tele) |
| Field of View |
Horizontal field of view: 50.8° to 1.7°(Wide-Tele) Vertical field of view: 29.4° to 1°(Wide-Tele) Diagonal field of view: 57.4° to 2°(Wide-Tele) |
| Working Distance |
10 to 1500 mm (wide-tele) |
| Aperture Range |
F1.5 to F3.4 |
| General |
| Language (Web Browser Access) |
32 languages. English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Power Supply |
24 VAC, 2.5 A, 50/60Hz and Hi-PoE, 42.5 to 57 VDC, 1.41 A Max. 40 W, including Max. 19 W for IR and Max. 10 W for heater |
| Working Environment |
Temperature: -30°C to 65°C (-22°F to 149°F), humidity: ≤ 90% |
| Protection Level |
IP66 Standard, IK10 (excluding glass window), 6000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Dimension |
Φ 220 mm × 353.4 mm (Φ 8.66" × 13.91") |
| Weight |
Approx. 4.5 kg (9.92 lb.) |
