LADE100100 is an X-ray baggage inspection system with a tunnel size of 1010*1010(mm) which provides an effective inspection on big baggage and other items. It helps to identify suspicious items such as weapons, liquids, explosives, drugs, knives, fire guns, bombs, toxic substances, flammable substances, ammunition and other dangerous objects which may lead to potential safety hazard by atomic number identification.High image quality in combination with automatic identification of suspicious objects allows the operator to quickly and effectively evaluate any luggage content.
Digi-Mark Solution authorized distributor of ZKTeco BLADE100100 X-Ray Baggage Inspection System in Bangladesh. You can buy the X-Ray Baggage Inspection System at best and dealer price from Our Head Office (Dhaka, Motijheel), IDB branch, Multiplan branch, Uttara Branch, Chittagong (chattagram) showrooms. For Lowest, dealer and best price Contact Us at 01979-234344.
DigiMark Solution has been Bangladesh's authorized ZKTeco distributor. Every ZKTeco BLADE100100 X-Ray Baggage Inspection System is 100% genuine with original firmware and official manufacturer warranty, backed by trained engineers for installation, configuration and RMA support nationwide. Bulk and corporate orders are welcome.
| SPECIFICATION | PR00436 |
|---|---|
| Tunnel Dimensions(W*H) | 1010 mm*1010 mm |
| Conveyor Speed: | 0.20m/sec ~ 0.40m/sec |
| Load on Conveyor | Max 200kg (evenly distributed) |
| Space Definition | HorizontalΦ1.0mm, VerticalΦ2.0mm |
| Steel Penetration | 35mm (guaranteed); 38mm (typical) |
| Wire Resolution | 38AWG (guaranteed); 40AWG (typical) |
| Dual-energy Detector | Yes |
| Number of Colors in X-ray Image: | 3 |
| Dimensions (L*W*H): | 4282mm*1482mm*1917mm |
| Dimensions of Operator Desk (L*W*H) | 797mm*789mm*1140mm |
| Package Dimensions (L*W*H) | 2900mm*1500mm*2100mm |
| Weight | 1260kg+70kg (Operator Desk) |
| Package Weight | 1530kg |
| Film Safety | ASA/ISO1600 standard of film safety |
| Single Inspection Dosage Rate | ≤1.0μGy |
| Operating Environment | |
| Operating Temperature | -10°C to +45°C |
| Storage Temperature | -20°C to +60°C |
| Humidity | 5 - 95%, non-condensing |
| Power Supply | 230VAC+/-10%/60/50Hz(EU) |
| Power Consumption | Approximately 1.0 kVA |
| Sound Pressure | |
| Tube Current | 0.5 - 1.2mA (adjustable) |
| Anode Voltage | 150 - 170kV (adjustable) |
| Generator Cool | Seal oil cooling/100% |
| Processor | I7-7700 |
| Monitor | 21” LED color |
| Memory | 8GB DDR4 |
| Hard Drive | 240GB SSD + 1TB HDD |
| Graphics Card | NVIDIA GeForce GTX 1660 Ti |
| USB Port | 4 ports |
| Software Features |
Perfect View (PV), Black/White (B/W), Pseudo Colors (PS), Inverse View (IN), High Penetration (HP), Real- time Image Processing, Image Zoom(64x), Image of Previous Baggage, Programmable Function Keys, Baggage Counter, Date/Time Indicator, Threat Image Projection(TIP), Automatic Identification of Suspicious, Cloud Remote Control, Status Monitoring of Walk Through, Metal Detector |
| Attribute / Feature | Specification Details |
|---|---|
| Tunnel Dimensions(W*H) | 1010 mm*1010 mm |
| Conveyor Speed: | 0.20m/sec ~ 0.40m/sec |
| Load on Conveyor | Max 200kg (evenly distributed) |
| Space Definition | HorizontalΦ1.0mm, VerticalΦ2.0mm |
| Steel Penetration | 35mm (guaranteed); 38mm (typical) |
| Wire Resolution | 38AWG (guaranteed); 40AWG (typical) |
| Dual-energy Detector | Yes |
| Number of Colors in X-ray Image: | 3 |
| Dimensions (L*W*H): | 4282mm*1482mm*1917mm |
| Dimensions of Operator Desk (L*W*H) | 797mm*789mm*1140mm |
| Package Dimensions (L*W*H) | 2900mm*1500mm*2100mm |
| Weight | 1260kg+70kg (Operator Desk) |
| Package Weight | 1530kg |
| Film Safety | ASA/ISO1600 standard of film safety |
| Single Inspection Dosage Rate | ≤1.0μGy |
| Operating Environment | |
| Operating Temperature | -10°C to +45°C |
| Storage Temperature | -20°C to +60°C |
| Humidity | 5 - 95%, non-condensing |
| Power Supply | 230VAC+/-10%/60/50Hz(EU) |
| Power Consumption | Approximately 1.0 kVA |
| Sound Pressure | |
| Tube Current | 0.5 - 1.2mA (adjustable) |
| Anode Voltage | 150 - 170kV (adjustable) |
| Generator Cool | Seal oil cooling/100% |
| Processor | I7-7700 |
| Monitor | 21” LED color |
| Memory | 8GB DDR4 |
| Hard Drive | 240GB SSD + 1TB HDD |
| Graphics Card | NVIDIA GeForce GTX 1660 Ti |
| USB Port | 4 ports |
| Software Features | Perfect View (PV), Black/White (B/W), Pseudo Colors (PS), Inverse View (IN), High Penetration (HP), Real- time Image Processing, Image Zoom(64x), Image of Previous Baggage, Programmable Function Keys, Baggage Counter, Date/Time Indicator, Threat Image Projection(TIP), Automatic Identification of Suspicious, Cloud Remote Control, Status Monitoring of Walk Through, Metal Detector |
