MP60UB Mini Digital Mixer Amplifier with USB & Bluetooth
MP60UB is 1.5U designed Mini Digital amplifier with USB/FM and Bluetooth. The Speaker output is 70V/100V and 4-16Ω available, 3 Aux input, Min1 is 6.3 mm jack in front panel and Mic2 is XLR in rear panel, Phantom power available for Mic2. Individual volume control for each Mic and Aux, also provide Bass and Treble control. What's more, it also has EMC signal input for emergency situation. This product is the best Bluetooth amp, and also can be called small audio amplifier.
Digi-Mark Solution authorized distributor of DSPPA in Bangladesh. You can buy the DSPPA MP60UB Mini Digital Mixer Amplifier with USB & Bluetooth at best and dealer price from Our Head Office (Dhaka, Motijheel), IDB branch, Multiplan branch, Uttara Branch, Chittagong (chattagram) showrooms. For Lowest, dealer and best price Contact Us at 01979-234344.
Buy Genuine from DigiMark Solution
DigiMark Solution has been Bangladesh's authorized DSPPA distributor. Every MP60UB Mini Digital Mixer Amplifier with USB & Bluetooth is 100% genuine with original firmware and official manufacturer warranty, backed by trained engineers for installation, configuration and RMA support nationwide. Bulk and corporate orders are welcome.
100% Original Firmware Official Manufacturer Warranty Expert Technical Support
SPECIFICATION
MP60UB Mini Digital Mixer Amplifier with USB & Bluetooth
Model
MP60UB
Description
PA Amplifier with USB/SD & FM & Bluetooth
Rated power
60W
Speaker Outputs
100V or 70V & 4Ohms-8 Ohms-16 Ohms
Connector
Mic1 input by unbalance 6.3mm phone jack
Attenuation
Microphone1-3, line1-2 and Mp3/FM, bass/treble and master
MIC1 input sensitivity
5mV
MIC2 input sensitivity
5mV
MIC3 input sensitivity
5mV
AUX1 input sensitivity
350mV
AUX2 input sensitivity
350mV
EMC input sensitivity
350mV
MIC frequency response
180Hz～10kHz（±3dB）
AUX frequency response
70Hz～16kHz（±3dB）
Noise
<5mV (4 ohm load output terminal)
THD
<1% 1KHz
Protection
Short-circuit, clip, overload and high temp protection
Treble adjustment
10dB（±2）
Bass adjustment
10dB（±2）
Rated power Supply
AC~110-220V
Rated outpu voltage
60W/4Ω, AC220V
Priority
EMC > MIC1 > others
Machine size(L×W×H)
247*198*66mm
Packing size
343*302*121mm (1PS)
Maximum packing size
630*355*283mm (4PS)
Net Weight
2.6kg
Attribute / Feature
Specification Details
Model
MP60UB
Description
PA Amplifier with USB/SD & FM & Bluetooth
Rated power
60W
Speaker Outputs
100V or 70V & 4Ohms-8 Ohms-16 Ohms
Connector
Mic1 input by unbalance 6.3mm phone jack
Attenuation
Microphone1-3, line1-2 and Mp3/FM, bass/treble and master
MIC1 input sensitivity
5mV
MIC2 input sensitivity
5mV
MIC3 input sensitivity
5mV
AUX1 input sensitivity
350mV
AUX2 input sensitivity
350mV
EMC input sensitivity
350mV
MIC frequency response
180Hz～10kHz（±3dB）
AUX frequency response
70Hz～16kHz（±3dB）
Noise
<5mV (4 ohm load output terminal)
THD
<1% 1KHz
Protection
Short-circuit, clip, overload and high temp protection
