| Image Sensor |
Bullet channel: 1/3" Progressive Scan CMOS; PTZ channel: 1/2.8" progressive scan CMOS |
| Min. Illumination |
Bullet channel: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light; PTZ channel: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed |
1 s to 1/30,000 s |
| Focus |
Semi-auto, manual, auto |
| Day & Night |
ICR (Infrared Cut Filter Removal) |
| Zoom |
PTZ channel: 25x optical, 16x digital |
| Day/Night Switch |
Day, night, auto, scheduled-switch |
| White Balance |
MWB, indoor, outdoor, fluorescent lamp, sodium lamp, ATW, auto, Locked WB |
| Max. Resolution |
Bullet channel: 2560 × 1440; PTZ channel: 2560 × 1440 |
| Lens |
Bullet channel: 2.8 mm; PTZ channel: 4.8 to 120 mm, 25x optical |
| Illuminator |
PTZ channel: IR; Bullet channel: White Light |
| Smart Supplement Light |
Yes |
| Supplement Light Range |
PTZ channel: up to 100 m; Bullet channel: up to 30 m |
| PTZ Movement Range (Pan) |
360° |
| PTZ Movement Range (Tilt) |
-15° to 90° (auto flip) |
| Pan Speed |
Configurable from 0.1° to 80°/s; preset speed: 80°/s |
| Tilt Speed |
Configurable from 0.1° to 80°/s; preset speed: 80°/s |
| Proportional Zoom |
Yes |
| Presets |
300 |
| Patrol Scan |
8 patrols, up to 32 presets for each patrol |
| Pattern Scan |
4 pattern scans |
| Power-Off Memory |
Yes |
| Park Action |
Preset, patrol scan, pattern scan, auto scan, tilt scan, random scan, frame scan, panorama scan |
| 3D Positioning |
Yes |
| PTZ Status Display |
Yes |
| Preset Freezing |
Yes |
| Scheduled Task |
Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output |
| Exception Detection |
IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot |
| Region Of Interest (ROI) |
8 fixed regions for each stream |
| Video Compression |
H.265, H.264, MJPEG |
| Video Bit Rate |
32 kbps to 16384 kbps |
| H.264 Type |
Baseline profile, main profile, high profile |
| H.265 Type |
Main profile |
| H.264+ |
Yes |
| H.265+ |
Yes |
| SVC |
Yes |
| Audio Compression |
G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC |
| Audio Bit Rate |
32 to 192 Kbps (MP2L2), 16 to 64Kbps (AAC-LC) |
| Audio Sampling Rate |
8 kHz, 16 kHz, 32 kHz, 48 kHz |
| Environment Noise Filtering |
Yes |
| Smart Record |
ANR, Dual-VCA |
| Network API |
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| Network Storage |
NAS (NFS, SMB/ CIFS); ANR |
| Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets |
| Simultaneous Live View |
20 |
| User/Host |
32 |
| Security Measures |
Authenticated username and password, MAC address binding, HTTPS encryption, 802.1X authenticated access, IP address filter |
| Client |
iVMS-4200, Hik-Connect |
| Web Browser |
IE 10+, Chrome 57+, Firefox 52+, Safari 12+ |
| Image Settings |
Sharpness, saturation, brightness, contrast |
| Wide Dynamic Range (WDR) |
120 dB |
| SNR (Signal-to-Noise Ratio) |
≥ 52 dB |
| Defog |
Digital defog |
| Image Stabilization |
EIS |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Regional Focus |
Yes |
| Regional Exposure |
Yes |
| Image Parameters Switch |
Yes |
| Privacy Mask |
Bullet channel: 8 programmable polygon privacy masks; PTZ channel: 24 programmable polygon privacy masks; mask color or mosaic configurable |
| Communication Interface |
RJ45, self-adaptive 10M/100M Ethernet port |
| On-Board Storage |
Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB |
| Alarm Input |
1 alarm input |
| Alarm Output |
1 alarm output |
| Audio Input |
1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10% |
| Audio Output |
1 audio output, line level, impedance: 600 Ω |
| Basic Event |
PTZ channel: motion detection, video tampering alarm; |
