Networking Components B&TON PoE Gigabit switch 24 port 48~52V power supply
B&TON PoE Gigabit switch 24 port 48~52V power supply
B&TON PoE Gigabit switch 24 port 48~52V power supply

B&TON PoE Gigabit switch 24 port 48~52V power supply

not inserted
Price 0
Status Call For Price
Product Code PR01061
Brand B&TON
Model B&TON 24 Port Switch
Features

    • IEEE 802.3af/at power on POE ports
    • Supply power to wireless access points and surveillance cameras over Cat cable
    • POE ports support MDI/MDIX
    • Support PoE power up to 15.4W(IEEE802.3af)/25.5W(IEEE802.3at) for PoE ports
    • POE Lines: End-Span(12+,36-), Mid-Span(25+,78-)

Hotline: 01979234344 | Corporate: 01979234319
No Brochure
Share On :
Last Modified On: 13-07-2024

B&TON 10/100/1000Mbits PoE Gigabit switch 24 port 48~52V power supply

The POE switch provides power and data transmission via Cat cables. POE ports supply power at the standard of IEEE802.3af/at. Auto-sensing function can supply power to PD device (IEEE802.3af/at standard). If the PoE device disconnected, it would stop supplying power. The POE switch features simple and reliable design, automatic identification of PoE supply voltage and power, speed, full duplex and Auto Uplink cable type.



Features

  • IEEE 802.3af/at power on POE ports
  • Supply power to wireless access points and surveillance cameras over Cat cable
  • POE ports support MDI/MDIX
  • Support PoE power up to 15.4W(IEEE802.3af)/25.5W(IEEE802.3at) for PoE ports
  • POE Lines: End-Span(12+,36-), Mid-Span(25+,78-)
  • Support IEEE 802.3x flow control for Full-duplex Mode and back-pressure for Half-duplex Mode
  • LED indicators for monitoring power, link, activity and speed
  • Network Media: 10BASE-T: Cat3 or more UTP(≤250 meter);100BASE-TX: Cat5 or more UTP (≤100 meter); Cat6 or more UTP (≤150 meter)
  • Working Environment: Operating Temperature: 0 ° ~ 55 ° C; Storage Temperature: -20 ° ~ 75 ° C; Operating Humidity: 10% ~ 95%, non-condensing
  • Forwarding Mode: Store-And-Forward
  • MTBF: 100,000 hours

Digi-Mark Solution authorized distributor of B&TON PoE Gigabit switch in Bangladesh. You can buy the B&TON PoE Gigabit switch 24 port 48~52V power supply at best and dealer price from Our Head Office (Dhaka, Motijheel), IDB branch, Multiplan branch, Uttara Branch, Chittagong (chattagram) showrooms. We have dedicated Technical engineers to assist all over Bangladesh. Total set-up and after-sale support can be ensured at the best price. To know more details please Contact Us on our Facebook Page or 01979-234344.

24port POE 10/100/1000M series

POE Port

24 POE 10/100/1000Mbps

Uplink

2 SFP -10/100/1000Mbps

Bandwidth

52Gbps

Address Database Size

16K

Power Supply

AC110/220V

Max.Power Per Port

15.4W(IEEE802.3af) default, 25.5W(IEEE802.3at) optional

Network Protocols

IEEE 802.3,IEEE 802.3i 10BASE-T,IEEE 802.3u 100BASE-TX,
IEEE 802.3af/at,IEEE 802.3x

LED Display

Power, POE, Ethernet

Transmission Distance

100meter for UTP ports; 0~120km for Fiber ports

Fiber Specification

Fiber Port: SC(default), FC/ST/LC(SFP)
Wavelength/Distance:
Dual Fiber 850nm(550m);1310nm(2/20/40km);1550nm(60/80/100km)
Single Fiber 1310/1550nm(25/40km);1490/1550nm(60/80/100km)
