NexaKey NX-A8862W IP66 Outdoor Waterproof Exit Button

4.5 · 1 review · Model: NX-A8862W
Core Summary
  • IP66 protection
  • 4mm aluminium faceplate
  • Blue LED ring
  • Universal NO/NC/COM
Price On Request – best corporate rate
Dealer & project pricing available · prices exclude VAT
100% Genuine Original firmware
Warranty Official support
Nationwide Fast delivery
Authorized Distributor
Direct from Nexakey
Installation Support
Trained engineers
Quote in 3 Hours
Business hours reply
20+ Yrs Expertise
Since 2006 · 6 branches
At A Glance

Key Specifications

Waterproof
Type
DC 12V
Power Supply
NO / NC / COM
Output Contact
4mm Aluminium Alloy
Material
Blue — Steady On
LED Indicator
86 × 86 × 40 mm
Dimensions
Specs & Details

Full Product Information

Last Updated: 30-06-2026

NexaKey NX-A8862W IP66 Outdoor Waterproof Exit Button

The NexaKey NX-A8862W IP66 Outdoor Waterproof Exit Button is a rugged, heavy-duty exit solution engineered for access control installations where standard indoor buttons simply cannot survive — outdoor gates, perimeter doors, car parks, loading bays, industrial sites, and exposed building entries. Built to endure Bangladesh's harsh monsoon climate, dust, and high humidity, the NX-A8862W carries a full IP66 outdoor waterproof rating, sealing it completely against driving rain and airborne dust for consistent, maintenance-free performance in demanding field conditions.

The faceplate is constructed from a 4mm thick aluminium alloy panel — one of the thickest in the NexaKey exit button lineup — delivering genuine vandal resistance in high-risk perimeter environments such as factory gates, warehouse loading docks, and secured parking entry points. Where plastic-bodied buttons crack, warp, or fade under UV exposure and physical impact, the NX-A8862W's solid alloy body remains structurally sound through years of daily outdoor use.

Navigation at night or in low-visibility conditions is addressed by a steady blue LED illuminated ring that permanently marks the button position in darkness — ensuring users locate and activate the exit point instantly without fumbling or hesitation. This is a particularly valued feature at car park barriers, gated communities, and industrial shift-change entry points where staff operate around the clock in variable lighting conditions.

Electrically, the NX-A8862W operates on a standard DC 12V power supply and delivers NO/NC/COM dry-contact relay outputs — ensuring universal plug-and-play compatibility with every major access controller, magnetic lock, electric strike, and electromagnetic lock deployed across commercial and industrial installations in Bangladesh. Its customizable panel logo further allows system integrators and facility managers to brand the button face for corporate lobbies, branded premises, or multi-tenant properties.

Certified to CE, FCC, RoHS, and IP66 international standards and backed by a 12-month manufacturer warranty, the NX-A8862W is a fully compliance-safe investment for outdoor access control projects in Bangladesh's banking, industrial, government, and commercial sectors.

DigiMark Solution is the authorised NexaKey dealer in Bangladesh, delivering genuine, warranty-backed devices with professional installation support and nationwide coverage across Dhaka, Chittagong, and all major districts. Buy the NexaKey NX-A8862W IP66 Outdoor Waterproof Exit Button at the best dealer price today.

Buy Genuine from DigiMark Solution

DigiMark Solution has been Bangladesh's authorized Nexakey distributor. Every NexaKey NX-A8862W IP66 Outdoor Waterproof Exit Button is 100% genuine with original firmware and official manufacturer warranty, backed by trained engineers for installation, configuration and RMA support nationwide. Bulk and corporate orders are welcome.

100% Original Firmware Official Manufacturer Warranty Expert Technical Support
Specification Value
Model NX-A8862W
Type Waterproof Exit Button (Outdoor)
Power Supply DC 12V
Output Contact NO / NC / COM
Protection Rating IP66 (dust-tight, jet-water resistant)
Material 4mm Aluminium Alloy faceplate
LED Indicator Blue (steady, illuminated ring)
Dimensions 86 × 86 × 40 mm
Mounting Surface mount
Panel Logo Customizable
Warranty 12 Months
Certifications CE · FCC · RoHS · IP66



IP66 means the unit is completely dust-tight (6) and protected against powerful water jets from any direction (second 6). It handles Bangladesh's monsoon rain and pressure-washing of outdoor areas.

The NX-A8862W has a sealed aluminium housing rated IP66. Standard indoor buttons (like the NX-K86C or A86H) use ABS plastic with no IP rating and will degrade quickly outdoors.

The NX-A8862W is 40mm deep and mounts directly on a flat surface — no separate back-box required. Ensure cable entry points are sealed with weatherproof glands.

Yes. Wire the NO output to the barrier controller's trigger input — standard practice for pedestrian gate-release installations.

NexaKey is distributed exclusively by DigiMark Solution in Bangladesh, so you get genuine stock with an official warranty. Exact pricing depends on quantity and project scope — tap Get Best Price or WhatsApp 01979234342 for a same-day quote. We don't publish fixed retail prices to protect dealer channel trust

Yes — every NexaKey unit comes from DigiMark Solution's genuine stock with an official warranty and nationwide after-sales support, including technical assistance and RMA handling.
