| Protocols/Standards |
SIP RFC3261, BFCP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP, TCP/IP/UDP, IPv6, FEC, FECC, H.323, Q.931, H.224, H.281, H.225.0, H.239, H.241, H.245, H.460.18 and H.460.19 |
| Camera |
1/3” 2 Megapixel CMOS 1920Hx1080V@30fps |
| Lens |
12x optical zoom, +/-23° tilt, +/- 90° pan, 70°(W)*- 6.3° (T) field of view |
| Network Interface |
1× RJ45 10/ 100/ 1000 Mbps port |
| Wi-Fi |
Yes, integrated dual-band 802.11 a/b/g/n (2.4GHz & 5GHz) |
| Bluetooth |
Yes, integrated. Bluetooth 4.0 + EDR |
| Video Outputs |
3x HDMI up to 1080p with CEC |
| Video Input |
1x VGA/1x HDMI with resolution up to 1080p |
| Microphone/Speaker |
External MIC/Speaker, built-in MIC, cascadable external MIC/speaker (pending) |
| Remote Control |
Bluetooth remote control with multi-touch touchpad |
| Auxiliary Ports |
1x USB 2.0, SD, external speaker port, reset pin |
| Graphic Display |
OLED with 128x32 resolution |
| Voice Codecs |
G.711μ/a, G.722 (wide-band), iLBC (pending), Opus, G.722.1, G.722.1c (pending), in-band and out-of-band DTMF (In audio, RFC2833, SIP INFO) |
| Video Codecs |
H.264 BP/MP/HP, video resolution up to 1080p, frame rate up to 30 fps, bitrate up to 4Mbps |
