Product Code PR01095
Brand ZKTeco
Model PE082-120-G
Features

    • 8*10/100/1000M PoE Port +2*gigabit network RJ45 port (10/100/1000 Mbps self-adaptation)
    • Conforms to IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
    • Comply with IEEE802.3at (30W) and IEEE802.3af (15.4w)
    • Max. PoE power output 30W for each port
    • Flow Control for Full Duplex operation and back pressure for Half Duplex Ope
    • Support RJ45 Auto-MDI/MDIX
    • With panel indicator for monitoring status and failure analysis

Hotline: 01979234344 | Corporate: 01979234316
Download Brochure
Share On :
Last Modified On: 02-02-2023

PE082-120-G is an advanced Ethernet PoE switch, providing a network point for data transmission and power supply, and supporting 10/100/1000 Mbps negotiated Ethernet interfaces or ports. It has 8 Gigabit PoE ports that can provide standard IEEE802.3af/at power supply through network cables. Because of the advanced self-sensing algorithm for supplying power over IEEE802.3af/at, the connected PoE or non-PoE standard equipment is safely protected.

It can be widely used in Ethernet access scenarios such as small and medium-sized enterprises, hotels, and schools, contributing to a high-performance network.

Model Number PE082-120-G
Port Type 8*10/100/1000M PoE Port +2*gigabit network RJ45
Switching Capacity 20Gbps
Packet Forwarding Rate 14.88Mpps
Internal Cache 1.5M
MAC Address Table 2K
Jumbo Frames 9216Kbytes
Forwarding Mode Store-and-Forward switching
Mean Time Between Failure (MTBF) 100000 hours
Standards IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x
  10Base-T: Cat3/Cat4/Cat5/Cat5e UTP/STP(≤100m) 100Base-TX : Cat5/Cat5e UTP/STP(≤100m) 1000Base-TX : Cat5/Cat5e UTP/STP(≤100m)
  IEEE802.3af (15.4W) IEEE802.3at (30W)
Power supply AC INPUT (100-240V) 50/60Hz 52V/2.3A output
Operating Temperature -20~50°C
Storage Temperature -40~85°C
Operating Humidity 10%~90%, non-condensing
Storage Humidity 5%~90%, non-condensing
Product Dimensions(L*W*H) 220*161*36.5(mm)
Packing Dimensions(L*W*H) 303*190*60(mm)
Net Weight 0.79kg
Gross Weight 1.06kg
