Supports (IP Video input) |
Network camera / ONVIF Profile S / DVR / NVR / Video encoder / Navigator |
Input(IP video input) |
8 CH |
Resolution( IP video input ) |
4K / 5M / 4M / 3M / 1080P / 1.3M / 1M / 960H / D1 / VGA / CIF |
Maximum Frame Rate ( IP video input ) |
240 FPS |
Output (Video output) |
HDMI 1.4 (4K 30P) / VGA 1080P |
Spot monitor (Video Display) |
HDMI & VGA sync output |
Split Screen |
1 / 4 / 8 / 9 split division, sequence mode, freeze, alarm display |
Digital zoom |
Up to 64× on live and playback |
Video Compression |
H.264 / H.265 |
Maximum Network Throughput |
64Mbps |
Recording Resolution |
CIF ~ 4K |
Frame Rate |
Single channel up to 1080P 60 FPS record |
Application/ Recording Mode |
Manual, schedule (continue, event, none) |
Recording schedule |
Each channel 7day × 24 hours time table, recording mode configurable |
Alarm event actions |
Motion grid (20×12, multi-level sensitivities) / network camera event / DI |
Metadata options |
POS
RFID AND PIN CONTROLLER
USER DEFINED 2
BARCODE SCANNER
GPS
LPR (Denial, Allowed, Visitor) |
Alarm Notification (Recording) |
Alarm notification iOS、android / E-Mail / FTP / buzzer / DO |
Playback Search |
Alarm event / Operation event / System event / Meta data event / Time search |
Playback Display |
8CH synchronous playback |
Playback Resolution |
CIF ~ 4K |
Max. frame rate (Playback) |
Up to 1080P 60FPS |
Playback Speed |
Fast rewind 2× ~ 64× / Fast forward 2× ~ 64× / Slow motion 1/2 ~ 1/16 |
Internal HDD / Swap Drive Bay |
2 × 3.5" HDD (Up to 16TB supported), Compatibility List https://www.meritlilin.com/compatiblelist/nvr1dvr3en.html |
USB Flash Disk(Backup) |
Up to 128 GB supported |
Network Backup |
Via HTTP / FTP / Network Places |
DVD DVD/RW(Backup) |
External USB DVD / RW |
Audio Input |
8 CH (Network camera), G.711 u-law 8K & AAC |
Audio Output |
RCA × 1 (0.7Vp-p, 300 Hz to 3KHz) |
Network Camera Two Way Audio / IP camera 2-way audio |
Yes |
Network ports |
RJ-45 Gigabit Ethernet × 1, RJ-45 100Mbps PoE × 8 (802.3af) |
Protocols |
ARP、TCP/IP、UDP、HTTP、HTTPS、SMTP、SNMP、FTP、DDNS、PPPoE、NTP、RTP、 RTSP、DHCP、ONVIF Profile S |
Web (Network) |
Direct internet browser access / Multiple users access |
Mobile Application |
iOS / Android supported |
P2P(Network) |
APP scan QR Code / UID connection |
RTSP service |
RTP UDP/ RTSP TCP supported |
IPScan / WS-Discovery( Network ) |
Network camera plug and play via PoE port, otherwise WS-Discovery and IP Scan, automatically quick IP address setup for network cameras also available |
Network |
Live / playback / backup / menu configuration / event log |
VMS |
Navigator |
Backup / Playback (Software) |
Remote Playback Manager / Backupman, multiple NVRs file download and multi-channel playback |
Digital watermark (Video tamper resistance) |
support digital watermark feature to ensure the backup footage is not got forged and modified |
Ports |
DI × 8 and DO × 1 (With programmable condition) |
Reports( System ) |
Alarm event, operation, configuration and system execution log full reports exporting over HTTP or USB |
Authentication ( System ) |
User authentication with feature configurable and IP address blocking |
Languages |
Arabic, Traditional Chinese, Simplified Chinese, English, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Turkish |
HDD Inspection(System) |
S.M.A.R.T monitoring / File system de-fragmentation/ IO read write error |
Recording day |
Automatic recording day calculator |
Time |
Daylight saving / NTP / External USB GPS time sync / Keyboard |
PTZ protocol |
HTTP、ONVIF |
Keyboard Keypad |
Support PIH-931D keyboard input (Connector box required) |
USB to RS-232 |
Record external metadata via USB to RS-232 cable, display at live and playback |
RS-485 |
One set for keyboard controller |
Remote Controller |
Remote controller addressable up to 255 NVRs (Optional) |
Mouse |
Mouse click, drag and scroll |
Microphone |
USB Mic (Optional) |
Wi-Fi Dongle |
WiFi and 4G external USB dongle supported (Certified brand only) |
USB GPS Receiver |
Support |
CPU |
ARM Cortex A9 Dual Core |
OS |
Embedded Linux Kernel 4.9 |
WDT |
Hardware watchdog timer |
CE |
Yes, EMI Class B |
FCC |
Yes, EMI Class B |
Power Supply |
DC 48V 2A 120W (Max) for HDDs and cameras |
NVR Consumption (without HDD) |
≤ 8W |
Operating temperature |
0°C ~ 45°C |
Operating humidity |
5% ~ 80% |
Dimension (W×L×H) |
360 × 316 × 60 mm |
Weight |
≈2.5 KG (Without hard drive) |
