PA & Conference System MP912 4x4 Matrix Mixer Amplifier
MP912 4x4 Matrix Mixer Amplifier
MP912 4x4 Matrix Mixer AmplifierMP912 4x4 Matrix Mixer Amplifier

MP912 4x4 Matrix Mixer Amplifier

not inserted
Price 0
Status Pre Order
Product Code PR00685
Brand DSPPA
Model MP912 4x4 Matrix
Features

    • 4 separate amplifier outputs, each channel RMS 60W/120W
    • 5 AUX inputs, 3 balanced Mic input with phantom power supply
    • 4 remote paging stations, support cascaded linkage



Hotline: 01979234344 | Corporate: 01979234316
Download Brochure
Share On :
Last Modified On: 08-02-2023

MP912 4x4 Matrix Mixer Amplifier



MP906/MP912 series is multi zone amplifier, this four-channel matrix power amplifier is a kind of cost-effective professional intelligent address system combining the luxurious and high-grade aluminum-alloy panel with standard and exquisite case with an elegant appearance, and also suitable for household, factory, school, hospital, shop and other commercial application.
The amplification system of this integrated amplifier MP912 is designed with imported power tube, resulting in the strong power, wide frequency band, low noise, high fidelity and quality at the level of performance. In the equipment, there are four channels of power output in order to facilitate the user to access the back-end loudspeaker. With the perfect and reliable DC output protection, overload protection, short-circuit protection, and overheat protection, the safety performance of this equipment is improved. The technical essence of this product is focused on the super adaptability and perfect performance. MP906/MP912 series is the best mixer amplifier, which also can be called audio mixer amplifier.

Digi-Mark Solution authorized distributor of DSPPA in Bangladesh. You can buy the DSPPA MP912 4x4 Matrix Mixer Amplifier at best and dealer price from Our Head Office (Dhaka, Motijheel), IDB branch, Multiplan branch, Uttara Branch, Chittagong (chattagram) showrooms. For Lowest, dealer and best price Contact Us at 01979-234344.

Type

MP912

Rated output power

120W×4

Loudspeaker output

4-16Ω, 70V, 100V

Input sensitivity and input impedance

AUX1, AUX2, AUX3: (3±0.5mV/600Ω) ~(300±50mV /10KΩ) balanced input;

AUX4, AUX5: 300±50 mV /10 KΩ unbalanced input;

TEL:300±50mV /10 KΩ;

CALL STATION1, 2, 3:2000±100 mV/10KΩ balanced input

Tune

Bass 100Hz ±10±2 dB;

Treble 10000H ±10±2dB;

Frequency response

80Hz~16KHz

Signal to noise ratio

≥75 dB

AUX1---4 output level

2V/600Ω balanced output

MP3

Play documents in the formats of MP3, WMA, WAC and ACC stored in 32GU disk or transferred by bluetooth

Dimension of equipment(L×W×H mm)

483×132×440mm

Dimension of packing (L×W×H mm)

550×550×215mm

Net weight

28kg

Gross weight

30.5kg
